LCR2100 LCR METRE OWON 100 kHz Bench Oscilloscopes RS232, USB Interface LCD – Color Display 1 Analog Channel 30V Record, Save

DESCRIPTION : Consecutive test frequency Basic accuracy : 0.05% Measuring speed up to 40 times per second Use 9-range test, auto, lock and nominal ( the instrument automatically selects the best range based on nominal value) DCR measurement and internal D.C. bias voltage (±2.5V) 3.5”color LCD Interface : RS-232C, Handler, USB Host / Device Support SCPI and ModbusRTU communication protocol Specifications   Model NO. LCR2300 LCR2200 LCR2100 LCR2020 Test Function Cs-Rs, Cs-D, Cp-Rp, Cp-D, Lp-Rp, Lp-Q, Ls-Rs, Ls-Q, G-B, R-X, Z-θr, Z-θd, DCR Monitor Parameter Z, D, Q, θr, θd, R, X, G, B, Y, Vac, Lac, △, △% Test Frequency 10Hz～300kHz 10Hz～200kHz 10Hz～100kHz 10Hz～20kHz Basic Accuracy 0.05%(Slow/Med), 0.1%(Fast) Measurement Speed 40 times/s, 10 times/s, 3 times/s Display Rang L：0.00001uH ～ 9999.99H C：0.00001pF ～ 9999.99mF R,X,Z：0.00001Ω ～ 99.9999MΩ B,G:0.01nS～999.999S D：0.00001 ～ 9.99999 Q：0.00001 ～ 99999.9 θd: -179.999°～179.999° θr: -3.14159 ～ 3.14159 %: -999.999% ～ 999.999% Output impedance 30Ω、50Ω、100Ω Ranging Auto, Hold and Nominal range. Total 9 Ranges. DC Bias ( Internal ) -2.50V ~ 2.50V Correction Function OPEN/SHORT Beep Feature OFF/PASS/FAIL and HIGH/LOW tone Memory built-in 10 files Trigger Mode Internal, Manual, External and Remote Trigger. Interface USB Host / Device, RS232, Handler Display 3.5 inch LCD
